Tuner USB, HDMI LAN SMPS Sound LED Driver T-Con DC-DC Converter

Power Inductors

Catalog	Features	Series	Part Number	LxW mm	Height Max. mm	Inductance μH	DCR Max. mΩ	Isat Typ. A	Itemp Typ. A	Inquiry
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP201208BS	2.0x1.2	0.8	0.24~2.2	26.4~156	2.2~6	1.8~4.8	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP201210BS	2.0x1.2	1	0.24~2.2	25~156	2.4~6.1	1.8~4.9	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP201608BS	2.0x1.6	0.8	0.47~2.2	42~144	2.5~4.5	1.7~4	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP201610BS	2.0x1.6	1	0.47~2.2	40~132	2.7~5.8	2~4.2	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP252010BS	2.5x2.0	1	0.22~10	20~480	1.3~9.2	1~6.3	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP252012BS	2.5x2.0	1.2	0.47~10	36~432	1.4~6.7	1.1~4.4	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP322512BS	3.2x2.5	1.2	0.68~10	37.2~390	1.6~7.2	1.1~4.2	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP3020BS	3.0x3.0	2	2.2~4.7	60~120	2.8~4.2	2~3.2	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP4010BS	4.0x4.0	1	100	336	2	1.5	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP4020HL	4.0x4.0	2	0.33~15	8.4~288	3~17.5	2~10	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP4020QL	4.0x4.0	2	0.47~1	6.6~12	10~11.5	8.5~10	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP4020HL-A	4.0x4.0	2	1~10	39~228	3.8~11	1.9~5.5	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP4020HL-B	4.0x4.0	2	1~10	20.4~150	3.3~10.5	2.2~8	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP4030HL	4.0x4.0	3	0.47~22	10~252	3.3~17	2~9.5	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP4030H1-B	4.0x4.0	3	3.3~4.7	42~54	5.5~8.5	4.5~5.5	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP5015HL-B	5.0x5.0	1.5	0.12~10	3.7~159	3.3~30.5	2.2~18.9	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP5018HL	5.0x5.0	1.8	0.47	8.5	16.8	11.6	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP5020HL	5.0x5.0	2	1~6.8	16.8~108	5.2~12	3.9~8.5	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP5030HL-A	5.0x5.0	3	0.47~22	6.6~204	4.5~22	2.3~14.5	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP6020HL	6.0x6.0	2	1~6.8	15~84	5.2~12.5	4.2~8.2	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP7018HL	7.0x7.0	1.8	0.47~10	9.6~150	5~27	3.3~10.5	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP7024HL-A	7.0x7.0	2.4	2.2~15	17.4~162	5.2~12.5	3.3~9	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP7030HL	7.0x7.0	3	0.47~47	4.8~312	3.3~33	2.2~18	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP7030HL-A	7.0x7.0	3	1~22	9~168	5.2~21	3~13	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP7030HL-B	7.0x7.0	3	1~22	7.2~120	4.5~18.5	3.5~15	sms
picture_as_pdf	Shield Metal Round Wire Plating	MMP	CMI-MMP7030H1-B	7.0x7.0	3	3.3~6.8	21.6~36	9.5~14	6.3~9	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP252010MH	2.5x2.0	1	0.24~10	18~564	1.3~7.6	0.95~5.9	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP252012MH	2.5x2.0	1.2	0.24~6.8	20.4~312	1.8~9.9	1.4~5.7	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP4018MH	4.0x4.0	1.8	4.7	126	4	2.8	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP4020MH	4.0x4.0	2	1~10	36~216	2.8~8	2.1~5.1	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP4020HL	4.0x4.0	2	0.1~15	3.6~300	2.6~30	1.9~16.5	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP4020LH	4.0x4.0	2	0.22	6.4	28	12	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP4030HL	4.0x4.0	3	0.1~22	5.4~264	2.6~32	2.2~15	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP4040HL	4.0x4.0	4	2.2~15	25.2~228	2.6~7.5	2.6~7	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP5015HL	5.0x5.0	1.5	0.15~2.2	4.5~54	7.3~26	4.5~16	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP5018HL	5.0x5.0	1.8	0.47	9.6	16	10.5	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP5020HL	5.0x5.0	2	0.1~6.8	3~132	4.5~35	2.9~25	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP5030HL	5.0x5.0	3	0.33~22	4.8~220	2.8~25	2.2~15	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP5040HL	5.0x5.0	4	3.3~22	32.4~180	3.1~10	2.7~8	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP6012HL	6.0x6.0	1.2	0.1~10	5.4~312	3~32	1.9~14	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP6015HL	6.0x6.0	1.5	1~10	30~228	3.1~10.5	2.2~6.2	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP6020LH	6.0x6.0	2	1~10	18.6~150	4.5~16	2.8~7.5	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP6030LH	6.0x6.0	3	2.2~3.3	21~30	10.5~14	7.5~8	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP6015HL-N	6.0x6.0	1.5	0.82~10	14.4~228	4~12	2.4~9.5	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP6018LH-N	6.0x6.0	1.8	0.15~10	3.36~192	5~45	2.5~18	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP6024LH-N	6.0x6.0	2.4	0.1~10	2.4~96	6~65	3.7~23.5	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP6030LH-N	6.0x6.0	3	0.1~33	1.8~240	3.7~67	2.7~24	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP6030HL-N	6.0x6.0	3	1~47	7.5~360	2~18	1.8~14	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP6040HL-N	6.0x6.0	4	2.2~33	14.4~156	3.3~13.5	3.3~8.5	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP6050LH-N	6.0x6.0	5	0.68~0.82	4.8~7.2	26~27	14.5~14.7	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP6050HL-N	6.0x6.0	5	0.68~68	4.8~312	2.5~27	2.5~14.7	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP8040HL	8.0x8.0	5	0.22	1.2	60	55	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP8050HL	8.0x8.0	5	0.5~47	5.4~204	4.5~32	3.3~19.5	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP10030HL	10.0x10.0	3	0.15~22	0.9~108	5.5~65	5.5~36	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP10030LH	10.0x10.0	3	0.68~10	4.8~72	10~42	4.8~21	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP10040LL	10.0x10.0	4	0.15~56	0.6~240	4.5~80	3.8~34	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP10040LH	10.0x10.0	4	2.2~22	10.8~66	8.5~28	5.5~14	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP10055LH	10.0x10.0	5.5	1~100	3.3~252	4.2~50	4~24	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP10055HL	10.0x10.0	5.5	1	2.9	33	28	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP10055LL	10.0x10.0	5.5	22	54	8.5	6.3	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP10075LL	10.0x10.0	7.5	4.7~22	10.2~50.4	9~22	8~20	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP12055LH	12.0x12.0	5.5	0.47~47	1.9~108	8~65	5.3~37	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP12070LH	12.0x12.0	7	0.47~33	1.4~58	11~70	8~37.5	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP12070LL	12.0x12.0	7	3.3~5.6	6~10.2	22.5~32	16.5~23	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP12090LH	12.0x12.0	9	1~47	2.5~84	8~50	7.5~38	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP12100LL	12.0x12.0	10	2.2	2.8	34	52	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP13055LH	13.0x13.0	5.5	0.68~15	1.8~36	13~60	9.5~32	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP13055LL	13.0x13.0	5.5	10~33	24~54	8.3~13.5	6.5~10	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP13060LL	13.0x13.0	6	3.3	6.5	36	25	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP13065LL	13.0x13.0	6.5	2.8~8.2	3.7~14	17~35	14.5~26	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP13070LH	13.0x13.0	7	0.47~47	1.4~78	10~70	7~37.5	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP13070LL	13.0x13.0	7	6.8~56	10.8~102	7~24	6~22	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP13090LH	13.0x13.0	9	1~47	1.8~73.2	8.5~55	7.5~38	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP13090LL	13.0x13.0	9	1~3.3	1~4.8	30~40	29~34	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP15080SH	15.0x15.0	8.5	22	45			sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP17040HC	17.0x17.0	4	4.7	10	18	23.5	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP17040HL	17.0x17.0	4	10	27.6	18	11	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP17070QL	17.0x17.0	7	0.33	0.6	70	75.5	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP17070HL	17.0x17.0	7	0.47~100	0.9~168	7.5~85	6.5~55	sms
picture_as_pdf	Shield Metal Round Wire Pin	MMPP	CMI-MMPP17075HL	17.0x17.0	7.5	10	11.4	23	22	sms
picture_as_pdf	Semi-Shield Ferrite Round Wire Plating	DSS	CMI-DSS201610NH	2.0x1.6	1	0.24~10	40~1000	0.7~4.1	0.55~3.1	sms
picture_as_pdf	Semi-Shield Ferrite Round Wire Plating	DSS	CMI-DSS252010NH	2.5x2.0	1	1~22	120.9~2206.8			sms
picture_as_pdf	Semi-Shield Ferrite Round Wire Plating	DSS	CMI-DSS252012NH	2.5x2.0	1.2	0.47~22	79.3~2371.2			sms
picture_as_pdf	Semi-Shield Ferrite Round Wire Plating	DSS	CMI-DSS3010NH	3.0x3.0	1	1~56	84.5~2784			sms
picture_as_pdf	Semi-Shield Ferrite Round Wire Plating	DSS	CMI-DSS3012NH	3.0x3.0	1.2	0.82~68	39~2004			sms
picture_as_pdf	Semi-Shield Ferrite Round Wire Plating	DSS	CMI-DSS3015NH	3.0x3.0	1.5	1~100	50.7~3600			sms
picture_as_pdf	Semi-Shield Ferrite Round Wire Plating	DSS	CMI-DSS4012NH	4.0x4.0	1.2	0.82~100	65~2652			sms
picture_as_pdf	Semi-Shield Ferrite Round Wire Plating	DSS	CMI-DSS4018NH	4.0x4.0	1.8	0.5~330	27.3~7800			sms
picture_as_pdf	Semi-Shield Ferrite Round Wire Plating	DSS	CMI-DSS4020NH	4.0x4.0	2	0.47~100	23.4~1860			sms
picture_as_pdf	Semi-Shield Ferrite Round Wire Plating	DSS	CMI-DSS4030NH	4.0x4.0	3	0.47~470	14.3~6600			sms
picture_as_pdf	Semi-Shield Ferrite Round Wire Plating	DSS	CMI-DSS5020NH	5.0x5.0	2.1	1~100	26~1320			sms
picture_as_pdf	Semi-Shield Ferrite Round Wire Plating	DSS	CMI-DSS5040NH	5.0x5.0	4	1~2200	15.6~15600			sms
picture_as_pdf	Semi-Shield Ferrite Round Wire Plating	DSS	CMI-DSS6020NH	6.0x6.0	2	0.68~47	22.1~516			sms
picture_as_pdf	Semi-Shield Ferrite Round Wire Plating	DSS	CMI-DSS6028NH	6.0x6.0	2.8	1~1000	15.6~7540			sms
picture_as_pdf	Semi-Shield Ferrite Round Wire Plating	DSS	CMI-DSS6045NH	6.0x6.0	4.7	1~1500	14.3~7800			sms
picture_as_pdf	Semi-Shield Ferrite Round Wire Plating	DSS	CMI-DSS8040NH	8.0x8.0	4.2	0.82~1000	10.4~3360			sms

picture_as_pdf

Part Number
CMI-MMP201208BS
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 2.0x1.2
Height Max. mm : 0.8
Inductance μH : 0.24~2.2
DCR Max. mΩ : 26.4~156
Isat Typ. A : 2.2~6
Itemp Typ. A : 1.8~4.8
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP201210BS
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 2.0x1.2
Height Max. mm : 1
Inductance μH : 0.24~2.2
DCR Max. mΩ : 25~156
Isat Typ. A : 2.4~6.1
Itemp Typ. A : 1.8~4.9
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP201608BS
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 2.0x1.6
Height Max. mm : 0.8
Inductance μH : 0.47~2.2
DCR Max. mΩ : 42~144
Isat Typ. A : 2.5~4.5
Itemp Typ. A : 1.7~4
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP201610BS
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 2.0x1.6
Height Max. mm : 1
Inductance μH : 0.47~2.2
DCR Max. mΩ : 40~132
Isat Typ. A : 2.7~5.8
Itemp Typ. A : 2~4.2
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP252010BS
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 2.5x2.0
Height Max. mm : 1
Inductance μH : 0.22~10
DCR Max. mΩ : 20~480
Isat Typ. A : 1.3~9.2
Itemp Typ. A : 1~6.3
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP252012BS
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 2.5x2.0
Height Max. mm : 1.2
Inductance μH : 0.47~10
DCR Max. mΩ : 36~432
Isat Typ. A : 1.4~6.7
Itemp Typ. A : 1.1~4.4
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP322512BS
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 3.2x2.5
Height Max. mm : 1.2
Inductance μH : 0.68~10
DCR Max. mΩ : 37.2~390
Isat Typ. A : 1.6~7.2
Itemp Typ. A : 1.1~4.2
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP3020BS
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 3.0x3.0
Height Max. mm : 2
Inductance μH : 2.2~4.7
DCR Max. mΩ : 60~120
Isat Typ. A : 2.8~4.2
Itemp Typ. A : 2~3.2
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP4010BS
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 4.0x4.0
Height Max. mm : 1
Inductance μH : 100
DCR Max. mΩ : 336
Isat Typ. A : 2
Itemp Typ. A : 1.5
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP4020HL
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 4.0x4.0
Height Max. mm : 2
Inductance μH : 0.33~15
DCR Max. mΩ : 8.4~288
Isat Typ. A : 3~17.5
Itemp Typ. A : 2~10
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP4020QL
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 4.0x4.0
Height Max. mm : 2
Inductance μH : 0.47~1
DCR Max. mΩ : 6.6~12
Isat Typ. A : 10~11.5
Itemp Typ. A : 8.5~10
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP4020HL-A
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 4.0x4.0
Height Max. mm : 2
Inductance μH : 1~10
DCR Max. mΩ : 39~228
Isat Typ. A : 3.8~11
Itemp Typ. A : 1.9~5.5
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP4020HL-B
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 4.0x4.0
Height Max. mm : 2
Inductance μH : 1~10
DCR Max. mΩ : 20.4~150
Isat Typ. A : 3.3~10.5
Itemp Typ. A : 2.2~8
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP4030HL
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 4.0x4.0
Height Max. mm : 3
Inductance μH : 0.47~22
DCR Max. mΩ : 10~252
Isat Typ. A : 3.3~17
Itemp Typ. A : 2~9.5
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP4030H1-B
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 4.0x4.0
Height Max. mm : 3
Inductance μH : 3.3~4.7
DCR Max. mΩ : 42~54
Isat Typ. A : 5.5~8.5
Itemp Typ. A : 4.5~5.5
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP5015HL-B
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 5.0x5.0
Height Max. mm : 1.5
Inductance μH : 0.12~10
DCR Max. mΩ : 3.7~159
Isat Typ. A : 3.3~30.5
Itemp Typ. A : 2.2~18.9
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP5018HL
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 5.0x5.0
Height Max. mm : 1.8
Inductance μH : 0.47
DCR Max. mΩ : 8.5
Isat Typ. A : 16.8
Itemp Typ. A : 11.6
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP5020HL
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 5.0x5.0
Height Max. mm : 2
Inductance μH : 1~6.8
DCR Max. mΩ : 16.8~108
Isat Typ. A : 5.2~12
Itemp Typ. A : 3.9~8.5
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP5030HL-A
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 5.0x5.0
Height Max. mm : 3
Inductance μH : 0.47~22
DCR Max. mΩ : 6.6~204
Isat Typ. A : 4.5~22
Itemp Typ. A : 2.3~14.5
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP6020HL
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 6.0x6.0
Height Max. mm : 2
Inductance μH : 1~6.8
DCR Max. mΩ : 15~84
Isat Typ. A : 5.2~12.5
Itemp Typ. A : 4.2~8.2
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP7018HL
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 7.0x7.0
Height Max. mm : 1.8
Inductance μH : 0.47~10
DCR Max. mΩ : 9.6~150
Isat Typ. A : 5~27
Itemp Typ. A : 3.3~10.5
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP7024HL-A
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 7.0x7.0
Height Max. mm : 2.4
Inductance μH : 2.2~15
DCR Max. mΩ : 17.4~162
Isat Typ. A : 5.2~12.5
Itemp Typ. A : 3.3~9
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP7030HL
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 7.0x7.0
Height Max. mm : 3
Inductance μH : 0.47~47
DCR Max. mΩ : 4.8~312
Isat Typ. A : 3.3~33
Itemp Typ. A : 2.2~18
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP7030HL-A
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 7.0x7.0
Height Max. mm : 3
Inductance μH : 1~22
DCR Max. mΩ : 9~168
Isat Typ. A : 5.2~21
Itemp Typ. A : 3~13
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP7030HL-B
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 7.0x7.0
Height Max. mm : 3
Inductance μH : 1~22
DCR Max. mΩ : 7.2~120
Isat Typ. A : 4.5~18.5
Itemp Typ. A : 3.5~15
Inquiry sms

picture_as_pdf

Part Number
CMI-MMP7030H1-B
Feature :
Shield
Metal
Round Wire
Plating
Series : MMP
LxW mm : 7.0x7.0
Height Max. mm : 3
Inductance μH : 3.3~6.8
DCR Max. mΩ : 21.6~36
Isat Typ. A : 9.5~14
Itemp Typ. A : 6.3~9
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP252010MH
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 2.5x2.0
Height Max. mm : 1
Inductance μH : 0.24~10
DCR Max. mΩ : 18~564
Isat Typ. A : 1.3~7.6
Itemp Typ. A : 0.95~5.9
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP252012MH
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 2.5x2.0
Height Max. mm : 1.2
Inductance μH : 0.24~6.8
DCR Max. mΩ : 20.4~312
Isat Typ. A : 1.8~9.9
Itemp Typ. A : 1.4~5.7
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP4018MH
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 4.0x4.0
Height Max. mm : 1.8
Inductance μH : 4.7
DCR Max. mΩ : 126
Isat Typ. A : 4
Itemp Typ. A : 2.8
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP4020MH
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 4.0x4.0
Height Max. mm : 2
Inductance μH : 1~10
DCR Max. mΩ : 36~216
Isat Typ. A : 2.8~8
Itemp Typ. A : 2.1~5.1
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP4020HL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 4.0x4.0
Height Max. mm : 2
Inductance μH : 0.1~15
DCR Max. mΩ : 3.6~300
Isat Typ. A : 2.6~30
Itemp Typ. A : 1.9~16.5
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP4020LH
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 4.0x4.0
Height Max. mm : 2
Inductance μH : 0.22
DCR Max. mΩ : 6.4
Isat Typ. A : 28
Itemp Typ. A : 12
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP4030HL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 4.0x4.0
Height Max. mm : 3
Inductance μH : 0.1~22
DCR Max. mΩ : 5.4~264
Isat Typ. A : 2.6~32
Itemp Typ. A : 2.2~15
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP4040HL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 4.0x4.0
Height Max. mm : 4
Inductance μH : 2.2~15
DCR Max. mΩ : 25.2~228
Isat Typ. A : 2.6~7.5
Itemp Typ. A : 2.6~7
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP5015HL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 5.0x5.0
Height Max. mm : 1.5
Inductance μH : 0.15~2.2
DCR Max. mΩ : 4.5~54
Isat Typ. A : 7.3~26
Itemp Typ. A : 4.5~16
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP5018HL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 5.0x5.0
Height Max. mm : 1.8
Inductance μH : 0.47
DCR Max. mΩ : 9.6
Isat Typ. A : 16
Itemp Typ. A : 10.5
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP5020HL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 5.0x5.0
Height Max. mm : 2
Inductance μH : 0.1~6.8
DCR Max. mΩ : 3~132
Isat Typ. A : 4.5~35
Itemp Typ. A : 2.9~25
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP5030HL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 5.0x5.0
Height Max. mm : 3
Inductance μH : 0.33~22
DCR Max. mΩ : 4.8~220
Isat Typ. A : 2.8~25
Itemp Typ. A : 2.2~15
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP5040HL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 5.0x5.0
Height Max. mm : 4
Inductance μH : 3.3~22
DCR Max. mΩ : 32.4~180
Isat Typ. A : 3.1~10
Itemp Typ. A : 2.7~8
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP6012HL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 6.0x6.0
Height Max. mm : 1.2
Inductance μH : 0.1~10
DCR Max. mΩ : 5.4~312
Isat Typ. A : 3~32
Itemp Typ. A : 1.9~14
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP6015HL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 6.0x6.0
Height Max. mm : 1.5
Inductance μH : 1~10
DCR Max. mΩ : 30~228
Isat Typ. A : 3.1~10.5
Itemp Typ. A : 2.2~6.2
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP6020LH
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 6.0x6.0
Height Max. mm : 2
Inductance μH : 1~10
DCR Max. mΩ : 18.6~150
Isat Typ. A : 4.5~16
Itemp Typ. A : 2.8~7.5
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP6030LH
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 6.0x6.0
Height Max. mm : 3
Inductance μH : 2.2~3.3
DCR Max. mΩ : 21~30
Isat Typ. A : 10.5~14
Itemp Typ. A : 7.5~8
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP6015HL-N
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 6.0x6.0
Height Max. mm : 1.5
Inductance μH : 0.82~10
DCR Max. mΩ : 14.4~228
Isat Typ. A : 4~12
Itemp Typ. A : 2.4~9.5
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP6018LH-N
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 6.0x6.0
Height Max. mm : 1.8
Inductance μH : 0.15~10
DCR Max. mΩ : 3.36~192
Isat Typ. A : 5~45
Itemp Typ. A : 2.5~18
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP6024LH-N
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 6.0x6.0
Height Max. mm : 2.4
Inductance μH : 0.1~10
DCR Max. mΩ : 2.4~96
Isat Typ. A : 6~65
Itemp Typ. A : 3.7~23.5
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP6030LH-N
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 6.0x6.0
Height Max. mm : 3
Inductance μH : 0.1~33
DCR Max. mΩ : 1.8~240
Isat Typ. A : 3.7~67
Itemp Typ. A : 2.7~24
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP6030HL-N
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 6.0x6.0
Height Max. mm : 3
Inductance μH : 1~47
DCR Max. mΩ : 7.5~360
Isat Typ. A : 2~18
Itemp Typ. A : 1.8~14
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP6040HL-N
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 6.0x6.0
Height Max. mm : 4
Inductance μH : 2.2~33
DCR Max. mΩ : 14.4~156
Isat Typ. A : 3.3~13.5
Itemp Typ. A : 3.3~8.5
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP6050LH-N
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 6.0x6.0
Height Max. mm : 5
Inductance μH : 0.68~0.82
DCR Max. mΩ : 4.8~7.2
Isat Typ. A : 26~27
Itemp Typ. A : 14.5~14.7
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP6050HL-N
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 6.0x6.0
Height Max. mm : 5
Inductance μH : 0.68~68
DCR Max. mΩ : 4.8~312
Isat Typ. A : 2.5~27
Itemp Typ. A : 2.5~14.7
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP8040HL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 8.0x8.0
Height Max. mm : 5
Inductance μH : 0.22
DCR Max. mΩ : 1.2
Isat Typ. A : 60
Itemp Typ. A : 55
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP8050HL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 8.0x8.0
Height Max. mm : 5
Inductance μH : 0.5~47
DCR Max. mΩ : 5.4~204
Isat Typ. A : 4.5~32
Itemp Typ. A : 3.3~19.5
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP10030HL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 10.0x10.0
Height Max. mm : 3
Inductance μH : 0.15~22
DCR Max. mΩ : 0.9~108
Isat Typ. A : 5.5~65
Itemp Typ. A : 5.5~36
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP10030LH
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 10.0x10.0
Height Max. mm : 3
Inductance μH : 0.68~10
DCR Max. mΩ : 4.8~72
Isat Typ. A : 10~42
Itemp Typ. A : 4.8~21
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP10040LL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 10.0x10.0
Height Max. mm : 4
Inductance μH : 0.15~56
DCR Max. mΩ : 0.6~240
Isat Typ. A : 4.5~80
Itemp Typ. A : 3.8~34
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP10040LH
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 10.0x10.0
Height Max. mm : 4
Inductance μH : 2.2~22
DCR Max. mΩ : 10.8~66
Isat Typ. A : 8.5~28
Itemp Typ. A : 5.5~14
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP10055LH
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 10.0x10.0
Height Max. mm : 5.5
Inductance μH : 1~100
DCR Max. mΩ : 3.3~252
Isat Typ. A : 4.2~50
Itemp Typ. A : 4~24
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP10055HL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 10.0x10.0
Height Max. mm : 5.5
Inductance μH : 1
DCR Max. mΩ : 2.9
Isat Typ. A : 33
Itemp Typ. A : 28
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP10055LL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 10.0x10.0
Height Max. mm : 5.5
Inductance μH : 22
DCR Max. mΩ : 54
Isat Typ. A : 8.5
Itemp Typ. A : 6.3
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP10075LL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 10.0x10.0
Height Max. mm : 7.5
Inductance μH : 4.7~22
DCR Max. mΩ : 10.2~50.4
Isat Typ. A : 9~22
Itemp Typ. A : 8~20
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP12055LH
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 12.0x12.0
Height Max. mm : 5.5
Inductance μH : 0.47~47
DCR Max. mΩ : 1.9~108
Isat Typ. A : 8~65
Itemp Typ. A : 5.3~37
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP12070LH
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 12.0x12.0
Height Max. mm : 7
Inductance μH : 0.47~33
DCR Max. mΩ : 1.4~58
Isat Typ. A : 11~70
Itemp Typ. A : 8~37.5
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP12070LL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 12.0x12.0
Height Max. mm : 7
Inductance μH : 3.3~5.6
DCR Max. mΩ : 6~10.2
Isat Typ. A : 22.5~32
Itemp Typ. A : 16.5~23
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP12090LH
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 12.0x12.0
Height Max. mm : 9
Inductance μH : 1~47
DCR Max. mΩ : 2.5~84
Isat Typ. A : 8~50
Itemp Typ. A : 7.5~38
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP12100LL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 12.0x12.0
Height Max. mm : 10
Inductance μH : 2.2
DCR Max. mΩ : 2.8
Isat Typ. A : 34
Itemp Typ. A : 52
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP13055LH
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 13.0x13.0
Height Max. mm : 5.5
Inductance μH : 0.68~15
DCR Max. mΩ : 1.8~36
Isat Typ. A : 13~60
Itemp Typ. A : 9.5~32
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP13055LL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 13.0x13.0
Height Max. mm : 5.5
Inductance μH : 10~33
DCR Max. mΩ : 24~54
Isat Typ. A : 8.3~13.5
Itemp Typ. A : 6.5~10
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP13060LL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 13.0x13.0
Height Max. mm : 6
Inductance μH : 3.3
DCR Max. mΩ : 6.5
Isat Typ. A : 36
Itemp Typ. A : 25
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP13065LL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 13.0x13.0
Height Max. mm : 6.5
Inductance μH : 2.8~8.2
DCR Max. mΩ : 3.7~14
Isat Typ. A : 17~35
Itemp Typ. A : 14.5~26
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP13070LH
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 13.0x13.0
Height Max. mm : 7
Inductance μH : 0.47~47
DCR Max. mΩ : 1.4~78
Isat Typ. A : 10~70
Itemp Typ. A : 7~37.5
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP13070LL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 13.0x13.0
Height Max. mm : 7
Inductance μH : 6.8~56
DCR Max. mΩ : 10.8~102
Isat Typ. A : 7~24
Itemp Typ. A : 6~22
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP13090LH
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 13.0x13.0
Height Max. mm : 9
Inductance μH : 1~47
DCR Max. mΩ : 1.8~73.2
Isat Typ. A : 8.5~55
Itemp Typ. A : 7.5~38
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP13090LL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 13.0x13.0
Height Max. mm : 9
Inductance μH : 1~3.3
DCR Max. mΩ : 1~4.8
Isat Typ. A : 30~40
Itemp Typ. A : 29~34
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP15080SH
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 15.0x15.0
Height Max. mm : 8.5
Inductance μH : 22
DCR Max. mΩ : 45
Isat Typ. A :
Itemp Typ. A :
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP17040HC
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 17.0x17.0
Height Max. mm : 4
Inductance μH : 4.7
DCR Max. mΩ : 10
Isat Typ. A : 18
Itemp Typ. A : 23.5
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP17040HL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 17.0x17.0
Height Max. mm : 4
Inductance μH : 10
DCR Max. mΩ : 27.6
Isat Typ. A : 18
Itemp Typ. A : 11
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP17070QL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 17.0x17.0
Height Max. mm : 7
Inductance μH : 0.33
DCR Max. mΩ : 0.6
Isat Typ. A : 70
Itemp Typ. A : 75.5
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP17070HL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 17.0x17.0
Height Max. mm : 7
Inductance μH : 0.47~100
DCR Max. mΩ : 0.9~168
Isat Typ. A : 7.5~85
Itemp Typ. A : 6.5~55
Inquiry sms

picture_as_pdf

Part Number
CMI-MMPP17075HL
Feature :
Shield
Metal
Round Wire
Pin
Series : MMPP
LxW mm : 17.0x17.0
Height Max. mm : 7.5
Inductance μH : 10
DCR Max. mΩ : 11.4
Isat Typ. A : 23
Itemp Typ. A : 22
Inquiry sms

picture_as_pdf

Part Number
CMI-DSS201610NH
Feature :
Semi-Shield
Ferrite
Round Wire
Plating
Series : DSS
LxW mm : 2.0x1.6
Height Max. mm : 1
Inductance μH : 0.24~10
DCR Max. mΩ : 40~1000
Isat Typ. A : 0.7~4.1
Itemp Typ. A : 0.55~3.1
Inquiry sms

picture_as_pdf

Part Number
CMI-DSS252010NH
Feature :
Semi-Shield
Ferrite
Round Wire
Plating
Series : DSS
LxW mm : 2.5x2.0
Height Max. mm : 1
Inductance μH : 1~22
DCR Max. mΩ : 120.9~2206.8
Isat Typ. A :
Itemp Typ. A :
Inquiry sms

picture_as_pdf

Part Number
CMI-DSS252012NH
Feature :
Semi-Shield
Ferrite
Round Wire
Plating
Series : DSS
LxW mm : 2.5x2.0
Height Max. mm : 1.2
Inductance μH : 0.47~22
DCR Max. mΩ : 79.3~2371.2
Isat Typ. A :
Itemp Typ. A :
Inquiry sms

picture_as_pdf

Part Number
CMI-DSS3010NH
Feature :
Semi-Shield
Ferrite
Round Wire
Plating
Series : DSS
LxW mm : 3.0x3.0
Height Max. mm : 1
Inductance μH : 1~56
DCR Max. mΩ : 84.5~2784
Isat Typ. A :
Itemp Typ. A :
Inquiry sms

picture_as_pdf

Part Number
CMI-DSS3012NH
Feature :
Semi-Shield
Ferrite
Round Wire
Plating
Series : DSS
LxW mm : 3.0x3.0
Height Max. mm : 1.2
Inductance μH : 0.82~68
DCR Max. mΩ : 39~2004
Isat Typ. A :
Itemp Typ. A :
Inquiry sms

picture_as_pdf

Part Number
CMI-DSS3015NH
Feature :
Semi-Shield
Ferrite
Round Wire
Plating
Series : DSS
LxW mm : 3.0x3.0
Height Max. mm : 1.5
Inductance μH : 1~100
DCR Max. mΩ : 50.7~3600
Isat Typ. A :
Itemp Typ. A :
Inquiry sms

picture_as_pdf

Part Number
CMI-DSS4012NH
Feature :
Semi-Shield
Ferrite
Round Wire
Plating
Series : DSS
LxW mm : 4.0x4.0
Height Max. mm : 1.2
Inductance μH : 0.82~100
DCR Max. mΩ : 65~2652
Isat Typ. A :
Itemp Typ. A :
Inquiry sms

picture_as_pdf

Part Number
CMI-DSS4018NH
Feature :
Semi-Shield
Ferrite
Round Wire
Plating
Series : DSS
LxW mm : 4.0x4.0
Height Max. mm : 1.8
Inductance μH : 0.5~330
DCR Max. mΩ : 27.3~7800
Isat Typ. A :
Itemp Typ. A :
Inquiry sms

picture_as_pdf

Part Number
CMI-DSS4020NH
Feature :
Semi-Shield
Ferrite
Round Wire
Plating
Series : DSS
LxW mm : 4.0x4.0
Height Max. mm : 2
Inductance μH : 0.47~100
DCR Max. mΩ : 23.4~1860
Isat Typ. A :
Itemp Typ. A :
Inquiry sms

picture_as_pdf

Part Number
CMI-DSS4030NH
Feature :
Semi-Shield
Ferrite
Round Wire
Plating
Series : DSS
LxW mm : 4.0x4.0
Height Max. mm : 3
Inductance μH : 0.47~470
DCR Max. mΩ : 14.3~6600
Isat Typ. A :
Itemp Typ. A :
Inquiry sms

picture_as_pdf

Part Number
CMI-DSS5020NH
Feature :
Semi-Shield
Ferrite
Round Wire
Plating
Series : DSS
LxW mm : 5.0x5.0
Height Max. mm : 2.1
Inductance μH : 1~100
DCR Max. mΩ : 26~1320
Isat Typ. A :
Itemp Typ. A :
Inquiry sms

picture_as_pdf

Part Number
CMI-DSS5040NH
Feature :
Semi-Shield
Ferrite
Round Wire
Plating
Series : DSS
LxW mm : 5.0x5.0
Height Max. mm : 4
Inductance μH : 1~2200
DCR Max. mΩ : 15.6~15600
Isat Typ. A :
Itemp Typ. A :
Inquiry sms

picture_as_pdf

Part Number
CMI-DSS6020NH
Feature :
Semi-Shield
Ferrite
Round Wire
Plating
Series : DSS
LxW mm : 6.0x6.0
Height Max. mm : 2
Inductance μH : 0.68~47
DCR Max. mΩ : 22.1~516
Isat Typ. A :
Itemp Typ. A :
Inquiry sms

picture_as_pdf

Part Number
CMI-DSS6028NH
Feature :
Semi-Shield
Ferrite
Round Wire
Plating
Series : DSS
LxW mm : 6.0x6.0
Height Max. mm : 2.8
Inductance μH : 1~1000
DCR Max. mΩ : 15.6~7540
Isat Typ. A :
Itemp Typ. A :
Inquiry sms

picture_as_pdf

Part Number
CMI-DSS6045NH
Feature :
Semi-Shield
Ferrite
Round Wire
Plating
Series : DSS
LxW mm : 6.0x6.0
Height Max. mm : 4.7
Inductance μH : 1~1500
DCR Max. mΩ : 14.3~7800
Isat Typ. A :
Itemp Typ. A :
Inquiry sms

picture_as_pdf

Part Number
CMI-DSS8040NH
Feature :
Semi-Shield
Ferrite
Round Wire
Plating
Series : DSS
LxW mm : 8.0x8.0
Height Max. mm : 4.2
Inductance μH : 0.82~1000
DCR Max. mΩ : 10.4~3360
Isat Typ. A :
Itemp Typ. A :
Inquiry sms

INQUIRY

※ If you have any questions about this product We will respond to your email address as soon as possible.
Your information will be sent to coilmaster@coilmaster.com.

Name*

Email*

Company

Phone

Subject*

Message

Privacy Policy

CoilMaster Co., Ltd. establishes and discloses the following guidelines for processing personal information in order to protect the personal information of the data subject (customer) and to handle complaints quickly and smoothly pursuant to Article 30 of the Personal Information Protection Act.

1. Purpose of processing personal information: CoilMaster Co., Ltd. processes personal information for the following purposes and shall not use it for any purpose other than the following.
- Verification, authentication, management, provision of goods or services, payment for goods or services, supply, and delivery of goods or services according to customer service provision.

2. Processing and retention period of personal information
① CoilMaster Co., Ltd. processes and retains personal information within the use period agreed upon by the data subject or as required by law when collecting personal information from the data subject.
② The specific processing and retention periods for personal information are as follows:
- Customer inquiry and management: Until the termination of the service usage agreement or membership cancellation, but if the bond and debt relationship remains, until the settlement of the relevant bond and debt relationship
- Record of supply of contracts, subscriptions, payments, goods, etc. in e-commerce: 5 years

3. Provision of Personal Information to Third Parties: CoilMaster Co., Ltd. does not provide personal information to third parties unless required by a separate consent of the data subject or by specific provisions of the law under Article 17 of the Personal Information Protection Act.

4. Entrustment of Personal Information Processing: CoilMaster Co., Ltd. does not outsource personal information processing tasks to external parties.

5. Rights and Obligations of the Data Subject and Legal Representative, and Exercise Methods: The data subject may exercise the following rights regarding personal
1. Request access to personal information.
2. Request correction if there are any errors.
3. Request deletion.
4. Request suspension of processing.
5. Types of Personal Information Processed: CoilMaster Co., Ltd. processes the following personal information:
- Name, address, phone number, mobile phone number, email address,
6. Personal Information Disposal: CoilMaster Co., Ltd. promptly disposes of personal information when it becomes unnecessary, such as upon the expiration of the personal information retention period or the achievement of the processing purpose.
7. CoilMaster Co., Ltd. disposes personal information in the following ways.
- Electronic files: Deleted or disk formatted
- Paper documentation: shredded or incinerated

8. Measures to Ensure the Security of Personal Information: CoilMaster Co., Ltd. takes the following measures to ensure the security of personal information:
- Administrative measures: Establishing and implementing internal management plans, providing regular education for employees and staff members.
- Technical measures: Setting passwords for the personal information processing system (or computers containing personal information) to control access, installing security programs such as antivirus software, encrypting files containing personal information.
- Physical measures: Controlling access to locations where personal information is stored or held, such as through locks and access controls.

9. Installation, Operation, and Rejection of Automatic Personal Information Collection Devices:
① CoilMaster Co., Ltd. uses 'cookies,' which store and retrieve usage information, to provide personalized services to users.
② Cookies are small pieces of information sent by a web server (HTTP) to a user's web browser and may be stored on the user's PC's hard disk.
A. Purpose of Cookie Use: Cookies are used to analyze the usage pattern, popular search terms, and secure connections of each service and website visited by the user, to provide optimized information to the user.
Installation, Operation, and Rejection of Cookies: Users can refuse to store cookies by setting options in the tool>internet options>privacy menu of their web browser. However, this may cause difficulties in using personalized service
C. Refusing to save cookies may cause difficulties in using customized services.

10. Personal Information Protection Manager: CoilMaster Co., Ltd. designates a personal information protection manager to be responsible for overall personal information processing, handling complaints from data subjects, and providing remedies related to personal information processing.

▶ Personal Information Protection Officer
Name: Cha Sang-yeop
Responsibility: CEO
Contact: 031-904-1444
E-mail : system@coilmaster.com
Fax: 063-263-1445

11. Change of personal information processing policy

This personal information processing policy will be applied from December 1, 2016.

I agree with the personal information processing policy guide.

I agree with the personal information processing policy guide.

Inquiry registration completed.

We will reply to your email address as soon as possible.

INQUIRY PRODUCT TOP

TV

Power Inductors

CMI-MMP201208BS

CMI-MMP201210BS

CMI-MMP201608BS

CMI-MMP201610BS

CMI-MMP252010BS

CMI-MMP252012BS

CMI-MMP322512BS

CMI-MMP3020BS

CMI-MMP4010BS

CMI-MMP4020HL

CMI-MMP4020QL

CMI-MMP4020HL-A

CMI-MMP4020HL-B

CMI-MMP4030HL

CMI-MMP4030H1-B

CMI-MMP5015HL-B

CMI-MMP5018HL

CMI-MMP5020HL

CMI-MMP5030HL-A

CMI-MMP6020HL

CMI-MMP7018HL

CMI-MMP7024HL-A

CMI-MMP7030HL

CMI-MMP7030HL-A

CMI-MMP7030HL-B

CMI-MMP7030H1-B

CMI-MMPP252010MH

CMI-MMPP252012MH

CMI-MMPP4018MH

CMI-MMPP4020MH

CMI-MMPP4020HL

CMI-MMPP4020LH

CMI-MMPP4030HL

CMI-MMPP4040HL

CMI-MMPP5015HL

CMI-MMPP5018HL

CMI-MMPP5020HL

CMI-MMPP5030HL

CMI-MMPP5040HL

CMI-MMPP6012HL

CMI-MMPP6015HL

CMI-MMPP6020LH

CMI-MMPP6030LH

CMI-MMPP6015HL-N

CMI-MMPP6018LH-N

CMI-MMPP6024LH-N

CMI-MMPP6030LH-N

CMI-MMPP6030HL-N

CMI-MMPP6040HL-N

CMI-MMPP6050LH-N

CMI-MMPP6050HL-N

CMI-MMPP8040HL

CMI-MMPP8050HL

CMI-MMPP10030HL

CMI-MMPP10030LH

CMI-MMPP10040LL

CMI-MMPP10040LH

CMI-MMPP10055LH

CMI-MMPP10055HL

CMI-MMPP10055LL

CMI-MMPP10075LL

CMI-MMPP12055LH

CMI-MMPP12070LH

CMI-MMPP12070LL

CMI-MMPP12090LH

CMI-MMPP12100LL

CMI-MMPP13055LH

CMI-MMPP13055LL

CMI-MMPP13060LL

CMI-MMPP13065LL

CMI-MMPP13070LH

CMI-MMPP13070LL

CMI-MMPP13090LH

CMI-MMPP13090LL

CMI-MMPP15080SH

CMI-MMPP17040HC

CMI-MMPP17040HL

CMI-MMPP17070QL
